Marco Oval Thermostatic Bar Valve with Adjustable Rigid Riser

Tap / Shower specification

WRAS Approved: No
TMV Approved: No
Minimum Operating Pressure (bar): 0.5
Maximum Operating Pressure (bar): 5
Flexible Tails Included: No
Number of tap holes required: N/a
Handle Type: Oval
Swivel Spout: N/a
Inlet Connection: 3/4 BSP
Outlet Connection: 1/2 BSP Handset
Tap Hole Diameter (mm): N/a
Tap Type description: Exposed Bar Valve
Includes Waste: N/a
Valve / Cartridge Type: Thermostatic & Quarter Turn Cartridge
Cartridge Spare code: 0

Flow Rates

0.2bar (l/min): 4.5
0.5bar (l/min): 7.6
1bar (l/min): 11
2bar (l/min): 15.5
3bar (l/min): 19.3

Showering specification

Anti-Scald: Yes
Shower Diverter function: Yes
Number of outlets: 2
Thermostatic Temperature control: Yes
Cool Touch: No
Shower Handset functions: 1
Minimum Working Pressure: 0.5
Maximum Working Pressure: 5
Shape: Oval
Pipe Centres (mm): 150
Inlet Connection: 3/4 BSP
Outlet Connection: 1/2 BSP Handset
Adjustable: Yes
Adjustment (mm): 0
Handle Type: Oval

Spares Codes

Diverter Spares: 0
Thermostatic cartridge Spares: 0
